CSS Outline

    The CSS outline property is pretty much similar to the border property. But the outline is drawn outside the element border. Here are some major differences which distinguish the outline property from border property.

    • The outline does not occupy space from the box model, but the border does.
    • The border is always in rectangular or square form but not outline.
    • Unlike border, we do not have different outline styling for all side. The outline has to be same for all sides of an element.

    Note: Internet Explorer6 and Netscape7 do not support outline property. In CSS we can use 4 properties to style or show the outline of an element.

    • outline-width: It set the width of the outline.
    • outline-style: It defines the different styling for the outline.
    • outline-color: It specifies the outline colour.
    • outline: It can specify all the above three properties in a single statement.

    CSS outline-width Property

    The outline-width property specifies the width for an element outline. And it accepts four values.

    • thin (means 1px)
    • medium (means 3px)
    • thick (means 5px)
    • Or we can simply use the length units in px, pt, cm, em etc.

    Example

    <p style="outline-width: thin; outline-style: solid; border: 3px solid red"> Paragraph with thin outline width and red border</p>

    <p style="outline-width: medium; outline-style: solid; border: 3px solid red"> Paragraph with medium outline width and red border</p>

    <p style="outline-width: thick; outline-style: solid; border: 3px solid red"> Paragraph with thick outline width and red border</p>

    <p style="outline-width: 7px; outline-style: solid; border: 3px solid red"> Paragraph with black 7px outline width and red border</p>

    Preview:

    Paragraph with thin outline width and red border

    Paragraph with medium outline width and red border

    Paragraph with thick outline width and red border

    Paragraph with black 7px outline width and red border

    Note: In the above preview you can see that the black outline is drawn outside the red border.

    CSS outline-style property

    The outline-style property is similar to the border-style property. It can specify the different type of styling to the outline structure. Here are the following values accepted by the outline-style:

    • dotted: Set the dotted outline
    • dashed: Set the dashed outline.
    • solid: Set a single line solid outline
    • double: Set two parallel lines outline.
    • groove: Set a 3d groove outline
    • ridge: Set a 3d ridged outline.
    • inset: Set a 3D inset outline.
    • outset: Set a 3D outset outline
    • none: Set no outline
    • hidden: Set a hidden outline

    Example

    <p style="outline-width: medium; outline-style: dotted; "> Paragraph with dotted Outline</p>
    <p style="outline-width: medium; outline-style: dashed; "> Paragraph with dashed outline</p>
    <p style="outline-width: medium; outline-style: solid; "> Paragraph with solid outline</p>
    <p style="outline-width: medium; outline-style: double; "> Paragraph with double outline</p>
    <p style="outline-width: medium; outline-style: groove; "> Paragraph with groove outline </p>
    <p style="outline-width: medium; outline-style: ridge; "> Paragraph with ridge outline.</p>
    <p style="outline-width: medium; outline-style: inset; "> Paragraph with inset outline.</p>
    <p style="outline-width: medium; outline-style: outset; "> Paragraph with outset outline</p>
    <p style="outline-width: medium; outline-style: none; "> Paragraph with none outline</p>
    <p style="outline-width: medium; outline-style: hidden; "> Paragraph with hidden outline</p>

    Preview

    Paragraph with dotted Outline

    Paragraph with dashed outline

    Paragraph with solid outline

    Paragraph with double outline

    Paragraph with groove outline

    Paragraph with ridge outline.

    Paragraph with inset outline.

    Paragraph with outset outline

    Paragraph with none outline

    Paragraph with hidden outline

    CSS Outline-Color Property

    Like other colour properties, it defines the colour for the element outline. It can accept value by color name, hex code, RGB code, etc.

    Example

    <p style="outline-width: medium; outline-style: solid; outline-color: blue "> Paragraph with solid Outline and blue colour</p>

    <p style="outline-width: medium; outline-style: dashed; outline-color: green "> Paragraph with dashed outline and green color</p>

    Preview

    Paragraph with solid Outline and blue colour

    Paragraph with dashed outline and green color

    CSS outline Property

    By far we have discussed different properties line outline-width, outline-color and outline-style to set the outline width, colour and style. But using the single outline property we can set all these three properties in a single statement.

    Syntax

    { outline: width style color;}

    Example

    <p style="outline: 3px dotted blue; "> Paragraph with 3px widht dotted and blue colour outline</p>
    <p style="outline: medium dashed green "> Paragraph with medium widht dashed and green color outline</p>

    Preview

    Paragraph with 3px widht dotted and blue colour outline

    Paragraph with medium widht dashed and green color outline

    CSS outline-offset Property

    outline-offset is an outline property which is used to define the spacing between the element border and outline. And it accepts length values in px, cm, em etc.

    Example

    <!DOCTYPE html>
    <html>
    <head>
    <title></title>
    </head>
    <body>
    <p style="outline: 3px dotted blue; outline-offset: 15px; border: 2px solid black;">
      Paragraph with 3px widht dotted and blue colour outline having 15px offset
    </p>
    </body>
    </html>

    Preview

    Paragraph with 3px widht dotted and blue colour outline having 15px offset

    Summary

    • The outline property in CSS is similar to the border.
    • There are some differences which distinct outline from the border.
    • It is not necessary that outline be always rectangular.
    • For an element, the outline shape and size are similar to all sides.
    • Like border-style, we have similar values for outline style.
