C++ Preprocessor

    Preprocessors are the special piece of code that we use in our program, and a preprocessor processes our program before compilation. There are many processes that include compiling and executing a program in C++. The process of Compiling a source code and Executing the code:

    • First, we save our source code as .cpp file.
    • And when we compile our source code, before the compiler compiles the code, the preprocessor processes the source code and generates an expanded file.
    • This expanded file includes all the dependencies of the source code, then the compiler compiles this expanded file and generates an object code file.
    • At last, the linker links this object code file to the object code of the library functions to generate the executable file program.exe.

    The preprocessors program starts with the hash symbol (#), #include is also a preprocessor directive. Preprocessors are not the general C++ statement that’s why we do not put a semicolon ; after the preprocessor statement. Apart from #include, #define, and #ifndef are examples of preprocessors.

    Types of Preprocessor Directives:

    There are 3 major types of Preprocessors directives:

    • Macros
    • File Inclusion
    • Conditional Compilation

    Macros

    Macros are the preprocessor directive which is used to give a special name to value and the name life remains throughout the program execution. To specify a macro we use the #define preprocessor directive, and the #define comprise of an identifier name or macro and value, every time the compiler sees the identifier it will replace it with the value.

    #define Syntax:

    #define identifier_name  value_to_replace_with

    Example

    #include <iostream>
using namespace std;
#define PI 3.14    //here PI is the macro and 3.14 is the value which replace PI.
int main ()
{
  cout<<"The value of PI is: "<<PI;
  return 0;
}

    Output

    The value of PI is: 3.14

    Behind the Code In this example using the #define preprocessor directive, we define the macro PI as 3.14 so every time the compiler encounters the PI in the program it substitutes it with 3.14 .

    Macro with arguments

    In the above example, we use #define to define an identifier we can also use #define to define a function. Example:

    #include <iostream>
using namespace std;
#define add(a,b) (a+b)
int main () {
  int sum;
  sum= add(3,4);    // compiler replace add(3,4) with (3+4)
  cout<<"Sum is: "<<sum;
  return 0;

}

    Output

    Sum is: 7

    Behind the Code In the above example, the compiler substitutes the add(3,4) statement with (3+4) .

    File Inclusion

    File Inclusion Preprocessors are used to include files in the source code, #include is the example of File inclusion, there are two types of file inclusion.

    • Build-in Header Files
    • User Define files

    Build-in header files

    #include <iostream> here <iostream> is a building header file and using the #include we include the iostream file in our source code that’s why we able to use statements like cout, cin, etc. Syntax

    #include<file_name>

    User-defined Files

    using the #include directive we can also include other C++ files in our own program. Syntax

    #include"filename"

    Conditional Compilation

    #endif and #ifdef are the examples of Conditional Compilation Directives, and these directives are used to compile or skip compile a specific part of the program on the basis of condition.

    Syntax:

     #ifdef identifier_name
    statement1;
    statement2;
    statement3;
    ……
#endif

    Summary

    • preprocessor, process action before the compilation process.
    • The preprocessor starts with the # symbol.
